YMF297

Il a le mode OPL et le mode de OPN, Le mode OPL a 2 modes : un à 2 opérateurs et l'autre à 4 opérateurs.

Mode OPN :

4 opérateurs
6 voix FM, 3 voix PSG, 1 voix générateur de bruit, 6 voix de rythme jouables simultanément.
Compatible avec le stéréo sauf le PSG

Mode OPL :

2 opérateurs / 4 opérateurs
De 11 à 20 voix FM.  (en fonction du mode choisi)
En mode 2 opérateurs, voix20 FM.
En mode 4 opérateurs, 6 voix FM jouables simultanément parmi 11 disponibles.


@@ -0,0 +1,335 @@
+/*
+**
+** File: ymdeltat.c
+**
+** YAMAHA DELTA-T adpcm sound emulation subroutine
+** used by fmopl.c(v0.37c-) and fm.c(v0.37a-)
+**
+** Base program is YM2610 emulator by Hiromitsu Shioya.
+** Written by Tatsuyuki Satoh
+**
+** History:
+** 05-08-2001 Jarek Burczynski:
+**  - now_step is initialized with 0 at the start of play.
+** 12-06-2001 Jarek Burczynski:
+**  - corrected end of sample bug in YM_DELTAT_ADPCM_CALC.
+**    Checked on real YM2610 chip - address register is 24 bits wide.
+**    Thanks go to Stefan Jokisch (address@hidden) for tracking down the
problem.
+**
+** TO DO:
+**             Check size of the address register on the other chips....
+**
+** Version 0.37e
+**
+** sound chips that have this unit
+**
+** YM2608   OPNA
+** YM2610/B OPNB
+** Y8950    MSX AUDIO
+**
+**
+*/
+
+/* This version of ay8910.c is a fork of the MAME 0.59 one, relicensed under
the LGPL.
+ *
+ * This library is free software; you can redistribute it and/or
+ * modify it under the terms of the GNU Lesser General Public
+ * License as published by the Free Software Foundation; either
+ * version 2.1 of the License, or (at your option) any later version.
+ *
+ * This library is distributed in the hope that it will be useful,
+ * but WITHOUT ANY WARRANTY; without even the implied warranty of
+ * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the GNU
+ * Lesser General Public License for more details.
+ *
+ * You should have received a copy of the GNU Lesser General Public
+ * License along with this library; if not, see <http://www.gnu.org/licenses/>.
+ */
+
+#ifndef YM_INLINE_BLOCK
+
+#include "ymdeltat.h"
+
+#define INLINE static inline
+
+/* -------------------- log output  -------------------- */
+/* log output level */
+#define LOG_ERR  3      /* ERROR       */
+#define LOG_WAR  2      /* WARNING     */
+#define LOG_INF  1      /* INFORMATION */
+#define LOG_LEVEL LOG_ERR
+
+#define LOG(n,x)
+
+UINT8 *ym_deltat_memory;      /* memory pointer */
+
+/* Forecast to next Forecast (rate = *8) */
+/* 1/8 , 3/8 , 5/8 , 7/8 , 9/8 , 11/8 , 13/8 , 15/8 */
+const INT32 ym_deltat_decode_tableB1[16] = {
+  1,   3,   5,   7,   9,  11,  13,  15,
+  -1,  -3,  -5,  -7,  -9, -11, -13, -15,
+};
+/* delta to next delta (rate= *64) */
+/* 0.9 , 0.9 , 0.9 , 0.9 , 1.2 , 1.6 , 2.0 , 2.4 */
+const INT32 ym_deltat_decode_tableB2[16] = {
+  57,  57,  57,  57, 77, 102, 128, 153,
+  57,  57,  57,  57, 77, 102, 128, 153
+};
+
+/* DELTA-T-ADPCM write register */
+void YM_DELTAT_ADPCM_Write(YM_DELTAT *DELTAT,int r,int v)
+{
+       if(r>=0x10) return;
+       DELTAT->reg[r] = v; /* stock data */
+
+       switch( r ){
+       case 0x00:      /* START,REC,MEMDATA,REPEAT,SPOFF,--,--,RESET */
+#if 0
+               case 0x60:      /* write buffer MEMORY from PCM data port */
+               case 0x20:      /* read  buffer MEMORY to   PCM data port */
+#endif
+               if( v&0x80 ){
+                       DELTAT->portstate = v&0x90; /* start req,memory
mode,repeat flag copy */
+                       /**** start ADPCM ****/
+                       DELTAT->volume_w_step = (double)DELTAT->volume *
DELTAT->step / (1<<YM_DELTAT_SHIFT);
+                       DELTAT->now_addr = (DELTAT->start)<<1;
+                       DELTAT->now_step = 0;
+                       DELTAT->acc      = 0;
+                       DELTAT->adpcml   = 0;
+                       DELTAT->adpcmd   = YM_DELTAT_DELTA_DEF;
+                       DELTAT->next_leveling=0;
+
+                       if( !DELTAT->step )
+                       {
+                               DELTAT->portstate = 0x00;
+                       }
+                       /**** PCM memory check & limit check ****/
+                       if(DELTAT->memory == 0){                        /*
Check memory Mapped */
+                               LOG(LOG_ERR,("YM Delta-T ADPCM rom not
mappedn"));
+                               DELTAT->portstate = 0x00;
+                       }else{
+                               if( DELTAT->end >= DELTAT->memory_size )
+                               {               /* Check End in Range */
+                                       LOG(LOG_ERR,("YM Delta-T ADPCM end out
of range: $%08xn",DELTAT->end));
+                                       DELTAT->end = DELTAT->memory_size - 1;
+                               }
+                               if( DELTAT->start >= DELTAT->memory_size )
+                               {               /* Check Start in Range */
+                                       LOG(LOG_ERR,("YM Delta-T ADPCM start
out of range: $%08xn",DELTAT->start));
+                                       DELTAT->portstate = 0x00;
+                               }
+                       }
+               } else if( v&0x01 ){
+                       DELTAT->portstate = 0x00;
+               }
+               break;
+       case 0x01:      /* L,R,-,-,SAMPLE,DA/AD,RAMTYPE,ROM */
+               DELTAT->pan = &DELTAT->output_pointer[(v>>6)&0x03];
+               break;
+       case 0x02:      /* Start Address L */
+       case 0x03:      /* Start Address H */
+               DELTAT->start  = (DELTAT->reg[0x3]*0x0100 | DELTAT->reg[0x2])
<< DELTAT->portshift;
+                       /*logerror("DELTAT start: 02=%2x 03=%2x
addr=%8xn",DELTAT->reg[0x2], DELTAT->reg[0x3],DELTAT->start );*/
+               break;
+       case 0x04:      /* Stop Address L */
+       case 0x05:      /* Stop Address H */
+               DELTAT->end    = (DELTAT->reg[0x5]*0x0100 | DELTAT->reg[0x4])
<< DELTAT->portshift;
+               DELTAT->end   += (1<<DELTAT->portshift) - 1;
+                       /*logerror("DELTAT end  : 04=%2x 05=%2x
addr=%8xn",DELTAT->reg[0x4], DELTAT->reg[0x5],DELTAT->end   );*/
+               break;
+       case 0x06:      /* Prescale L (PCM and Recoard frq) */
+       case 0x07:      /* Proscale H */
+       case 0x08:      /* ADPCM data */
+         break;
+       case 0x09:      /* DELTA-N L (ADPCM Playback Prescaler) */
+       case 0x0a:      /* DELTA-N H */
+               DELTAT->delta  = (DELTAT->reg[0xa]*0x0100 | DELTAT->reg[0x9]);
+                       /*logerror("DELTAT deltan:09=%2x
0a=%2xn",DELTAT->reg[0x9], DELTAT->reg[0xa]);*/
+               DELTAT->step     = (UINT32)( (double)(DELTAT->delta /*
*(1<<(YM_DELTAT_SHIFT-16)) */ ) * (DELTAT->freqbase) );
+               DELTAT->volume_w_step = (double)DELTAT->volume * DELTAT->step /
(1<<YM_DELTAT_SHIFT);
+               break;
+       case 0x0b:      /* Level control (volume , voltage flat) */
+               {
+                       INT32 oldvol = DELTAT->volume;
+                       DELTAT->volume = (v&0xff) * (DELTAT->output_range/256)
/ YM_DELTAT_DECODE_RANGE;
+//                                                             v         *
        ((1<<16)>>8)            >>      15;
+//                                             thus:   v         *
(1<<8)                          >>      15;
+//                                             thus: output_range must be (1
<< (15+8)) at least
+//                                                             v     *
((1<<23)>>8)            >>      15;
+//                                                             v         *
        (1<<15)                         >>      15;
+                       /*logerror("DELTAT vol = %2xn",v&0xff);*/
+                       if( oldvol != 0 )
+                       {
+                               DELTAT->adpcml        =
(int)((double)DELTAT->adpcml        / (double)oldvol * (double)DELTAT->volume);
+                               DELTAT->resample_step =
(int)((double)DELTAT->resample_step / (double)oldvol * (double)DELTAT->volume);
+                       }
+                       DELTAT->volume_w_step = (double)DELTAT->volume *
DELTAT->step / (1<<YM_DELTAT_SHIFT);
+               }
+               break;
+       }
+}
+
+void YM_DELTAT_ADPCM_Reset(YM_DELTAT *DELTAT,int pan)
+{
+       DELTAT->now_addr  = 0;
+       DELTAT->now_step  = 0;
+       DELTAT->step      = 0;
+       DELTAT->start     = 0;
+       DELTAT->end       = 0;
+       /* F2610->adpcm[i].delta     = 21866; */
+       DELTAT->volume    = 0;
+       DELTAT->pan       = &DELTAT->output_pointer[pan];
+       /* DELTAT->flagMask  = 0; */
+       DELTAT->acc       = 0;
+       DELTAT->adpcmd    = 127;
+       DELTAT->adpcml    = 0;
+       DELTAT->volume_w_step = 0;
+       DELTAT->next_leveling = 0;
+       DELTAT->portstate = 0;
+       /* DELTAT->portshift = 8; */
+}
+
+void YM_DELTAT_postload(YM_DELTAT *DELTAT,UINT8 *regs)
+{
+       int r;
+
+       /* to keep adpcml and resample_step */
+       DELTAT->volume = 0;
+       /* update */
+       for(r=1;r<16;r++)
+               YM_DELTAT_ADPCM_Write(DELTAT,r,regs[r]);
+       DELTAT->reg[0] = regs[0];
+       /* current rom data */
+       DELTAT->now_data = *(ym_deltat_memory+(DELTAT->now_addr>>1));
+
+}
+
+void YM_DELTAT_savestate(QEMUFile* f, YM_DELTAT *DELTAT)
+{
+       qemu_put_8s(f, &DELTAT->portstate);
+       qemu_put_be32s(f, &DELTAT->now_addr);
+       qemu_put_be32s(f, &DELTAT->now_step);
+       qemu_put_be32s(f, &DELTAT->acc);
+       qemu_put_be32s(f, &DELTAT->adpcmd);
+       qemu_put_be32s(f, &DELTAT->adpcml);
+       qemu_put_be32s(f, &DELTAT->next_leveling);
+       qemu_put_be32s(f, &DELTAT->resample_step);
+}
+
+int YM_DELTAT_loadstate(QEMUFile* f, YM_DELTAT *DELTAT)
+{
+       qemu_get_8s(f, &DELTAT->portstate);
+       qemu_get_be32s(f, &DELTAT->now_addr);
+       qemu_get_be32s(f, &DELTAT->now_step);
+       qemu_get_be32s(f, &DELTAT->acc);
+       qemu_get_be32s(f, &DELTAT->adpcmd);
+       qemu_get_be32s(f, &DELTAT->adpcml);
+       qemu_get_be32s(f, &DELTAT->next_leveling);
+       qemu_get_be32s(f, &DELTAT->resample_step);
+
+       return 0;
+}
+#else /* YM_INLINE_BLOCK */
+
+/* ---------- inline block ---------- */
+
+/* DELTA-T particle adjuster */
+#define YM_DELTAT_DELTA_MAX (24576)
+#define YM_DELTAT_DELTA_MIN (127)
+#define YM_DELTAT_DELTA_DEF (127)
+
+#define YM_DELTAT_DECODE_RANGE 32768
+#define YM_DELTAT_DECODE_MIN (-(YM_DELTAT_DECODE_RANGE))
+#define YM_DELTAT_DECODE_MAX ((YM_DELTAT_DECODE_RANGE)-1)
+
+extern const INT32 ym_deltat_decode_tableB1[];
+extern const INT32 ym_deltat_decode_tableB2[];
+
+#define YM_DELTAT_Limit(val,max,min)
+{

+       if ( val > max ) val = max;
+       else if ( val < min ) val = min;
+}
+
+/**** ADPCM B (Delta-T control type) ****/
+INLINE void YM_DELTAT_ADPCM_CALC(YM_DELTAT *DELTAT)
+{
+       UINT32 step;
+       int data;
+       INT32 prev_acc;
+       INT32 now_leveling;
+
+       DELTAT->now_step += DELTAT->step;
+       if ( DELTAT->now_step >= (1<<YM_DELTAT_SHIFT) )
+       {
+               step = DELTAT->now_step >> YM_DELTAT_SHIFT;
+               DELTAT->now_step &= (1<<YM_DELTAT_SHIFT)-1;
+               do{
+                       if ( DELTAT->now_addr == (DELTAT->end<<1) ) {   /*
12-06-2001 JB: corrected comparison. Was > instead of == */
+                               if( DELTAT->portstate&0x10 ){
+                                       /**** repeat start ****/
+                                       DELTAT->now_addr = DELTAT->start<<1;
+                                       DELTAT->acc      = 0;
+                                       DELTAT->adpcmd   = YM_DELTAT_DELTA_DEF;
+                                       DELTAT->next_leveling = 0;
+                               }else{
+                                       if(DELTAT->arrivedFlagPtr)
+                                               (*DELTAT->arrivedFlagPtr) |=
DELTAT->flagMask;
+                                       DELTAT->portstate = 0;
+                                       DELTAT->adpcml = 0;
+                                       now_leveling = 0;
+                                       return;
+                               }
+                       }
+                       if( DELTAT->now_addr&1 ) data = DELTAT->now_data & 0x0f;
+                       else
+                       {
+                               DELTAT->now_data =
*(ym_deltat_memory+(DELTAT->now_addr>>1));
+                               data = DELTAT->now_data >> 4;
+                       }
+
+                       DELTAT->now_addr++;
+                       /* 12-06-2001 JB: */
+                       /* YM2610 address register is 24 bits wide.*/
+                       /* The "+1" is there because we use 1 bit more for
nibble calculations.*/
+                       /* WARNING: */
+                       /* Side effect: we should take the size of the mapped
ROM into account */
+                       DELTAT->now_addr &= ( (1<<(24+1))-1);
+
+                       /* store accumulator value */
+                       prev_acc     = DELTAT->acc;
+                       /* Forecast to next Forecast */
+                       DELTAT->acc += (ym_deltat_decode_tableB1[data] *
DELTAT->adpcmd / 8);
+                       YM_DELTAT_Limit(DELTAT->acc,YM_DELTAT_DECODE_MAX,
YM_DELTAT_DECODE_MIN);
+                       /* delta to next delta */
+                       DELTAT->adpcmd = (DELTAT->adpcmd *
ym_deltat_decode_tableB2[data] ) / 64;
+                       YM_DELTAT_Limit(DELTAT->adpcmd,YM_DELTAT_DELTA_MAX,
YM_DELTAT_DELTA_MIN );
+                       /* calulate new leveling value */
+                       now_leveling      = DELTAT->next_leveling;
+                       DELTAT->next_leveling = prev_acc + ((DELTAT->acc -
prev_acc) / 2 );
+
+               }while(--step);
+
+/* #define YM_DELTAT_CUT_RE_SAMPLING */
+#ifdef YM_DELTAT_CUT_RE_SAMPLING
+               DELTAT->adpcml  = DELTAT->next_leveling * DELTAT->volume;
+               DELTAT->adpcml  = DELTAT->acc * DELTAT->volume;
+       }
+#else
+               /* delta step of resampling */
+               DELTAT->resample_step = (DELTAT->next_leveling - now_leveling)
* DELTAT->volume_w_step;
+//             DELTAT->resample_step = (DELTAT->next_leveling - now_leveling) *
+//                                                     ((double)DELTAT->volume
* DELTAT->step / (1<<YM_DELTAT_SHIFT));
+
+               /* output of start point */
+               DELTAT->adpcml  = now_leveling * DELTAT->volume;
+               /* adjust to now */
+               DELTAT->adpcml += (int)((double)DELTAT->resample_step *
((double)DELTAT->now_step/(double)DELTAT->step));
+       }
+       DELTAT->adpcml += DELTAT->resample_step;
+#endif
+       /* output for work of output channels (outd[OPNxxxx])*/
+       *(DELTAT->pan) += DELTAT->adpcml;
+}
+
+#endif /* YM_INLINE_BLOCK */
diff --git a/qemu/hw/ymdeltat.h b/qemu/hw/ymdeltat.h
new file mode 100644
index 0000000..9fea8f1
--- /dev/null
+++ b/qemu/hw/ymdeltat.h
@@ -0,0 +1,58 @@
+#ifndef __YMDELTAT_H_
+#define __YMDELTAT_H_
+
+#include "hw.h"
+#include "fm_def.h"
+
+#define YM_DELTAT_SHIFT    (16)
+
+/* adpcm type A and type B struct */
+typedef struct deltat_adpcm_state {
+       UINT8 *memory;
+       int memory_size;
+       double freqbase;
+       INT32 *output_pointer; /* pointer of output pointers */
+       int output_range;
+
+       UINT8 reg[16];                  /* adpcm registers              */
+       UINT8 portstate;                /* port status  : stop==0*/
+       int portshift;                  /* address shift bits   */
+       UINT8 now_data;                 /* current rom data             */
+       UINT32 now_addr;                /* current address              */
+       UINT32 now_step;                /* currect step                 */
+       UINT32 step;                    /* step
*/
+       UINT32 start;                   /* start address                */
+       UINT32 end;                             /* end address
*/
+       UINT32 delta;                   /* delta scale                  */
+       INT32 volume;                   /* current volume               */
+       INT32 *pan;                             /* pan : &output_pointer[pan] */
+       INT32 acc;                              /* shift Measurement value */
+       INT32 adpcmd;                   /* next Forecast                */
+       INT32 adpcml;                   /* current value                */
+       /* leveling and re-sampling state for DELTA-T */
+       INT32 volume_w_step;    /* volume with step rate */
+       INT32 next_leveling;    /* leveling value        */
+       INT32 resample_step;    /* step of re-sampling   */
+       /* external flag controll (for YM2610) */
+       UINT8 flagMask;                 /* arrived flag mask    */
+       UINT8 *arrivedFlagPtr;  /* pointer of arrived end address flag */
+}YM_DELTAT;
+
+/* static state */
+extern UINT8 *ym_deltat_memory;       /* memory pointer */
+
+/* before YM_DELTAT_ADPCM_CALC(YM_DELTAT *DELTAT); */
+#define YM_DELTAT_DECODE_PRESET(DELTAT) {ym_deltat_memory = DELTAT->memory;}
+
+void YM_DELTAT_ADPCM_Write(YM_DELTAT *DELTAT,int r,int v);
+void YM_DELTAT_ADPCM_Reset(YM_DELTAT *DELTAT,int pan);
+void YM_DELTAT_postload(YM_DELTAT *DELTAT,UINT8 *regs);
+void YM_DELTAT_savestate(QEMUFile* f, YM_DELTAT *DELTAT);
+int YM_DELTAT_loadstate(QEMUFile* f, YM_DELTAT *DELTAT);
+
+/* INLINE void YM_DELTAT_ADPCM_CALC(YM_DELTAT *DELTAT); */
+#define YM_INLINE_BLOCK
+#include "ymdeltat.c" /* include inline function section */
+#undef  YM_INLINE_BLOCK
+
+#endif


  This software is dual-licensed: it may be used in MAME and properly licensed
   MAME derivatives under the terms of the MAME license.  For use outside of
   MAME and properly licensed derivatives, it is available under the
   terms of the GNU Lesser General Public License (LGPL), version 2.1.
   You may read the LGPL at http://www.gnu.org/licenses/lgpl.html

   Changelog:
   Sep. 8, 2002 - fixed ymf278b_compute_rate when octave is negative (RB)
   Dec. 11, 2002 - added ability to set non-standard clock rates (RB)
                   fixed envelope target for release (fixes missing
           instruments in hotdebut).
                   Thanks to Team Japump! for MP3s from a real PCB.
           fixed crash if MAME is run with no sound.
   June 4, 2003 -  Changed to dual-license with LGPL for use in openMSX.
                   openMSX contributed a bugfix where looped samples were
            not being addressed properly, causing pitch fluctuation.

   With further improvements over the years by MAME team.

   TODO:
   - accurate timing of envelopes
   - LFO (vibrato, tremolo)
   - integrate YMF262 (used by Fuuki games, not used by Psikyo and Metro games)
   - able to hook up "Moonsound", supporting mixed ROM+RAM (for MSX driver in MESS)
