;/               __           _                              \
;|              / _|         (_)                             |
;|             | |_ _   _ ___ _  ___  _ __                   |
;|             |  _| | | / __| |/ _ \| '_ \                  |
;|             | | | |_| \__ \ | (_) | | | |                 |
;|             |_|  \__,_|___/_|\___/|_| |_| *               |
;|                                                           |
;|               The MSX C Library for SDCC                  |
;|                     V1.3 -  05-2020                       |
;|                                                           |
;|                Eric Boez &  Fernando Garcia               |
;|                                                           |
;|               A S M  S O U R C E   C O D E                |
;|                                                           |
;| https://github.com/Threetwosevensixseven/ayfxedit-improved|
;|                                                           |
;|          https://shiru.untergrund.net/software.shtml      |
;\___________________________________________________________/
;
;    AYFX Sound Effect Driver
;     based on Shiru's, modified by Artrag in April 6 2014
;
;    This AYFX Replayer can play up to 3 SoundFx at the same time, over the 3 PSG Channels
;
.area _DATA
DATA_AREA:
afxNoisePeriod: .ds 1
afxBnkAdr: .ds 2
afxAYREGS: .ds 14

; descriptors channels 11 bytes to the channel:
; 0 (2) the current address (the channel is free, if the high byte = $ 00)
; 2 (2) Time effect
; 4 (1) the volume
; 5 (1) bits of the mixer
; 6 (2) pitch period
; 8 (1) looping effect if != $00
; 9 (2) starting point if looping

afxChData: .ds 33
END_DATA_AREA:
; endmap

afxTonA= 0
afxTonB= 2
afxTonC= 4
afxNoise= 6
afxMixer= 7
afxAmplA= 8
afxAmplB= 9
afxAmplC= 10

loopingsfx= 0 ; sfx with $ up to loopingsfx (excluded) will loop, the higher $ will go once

; ------------------------------------------------- ------------- ;
; Initialization player effects. ;
; Turns off all channels , sets variables . ;
; ------------------------------------------------- ------------- ;
.area _CODE
_InitFX::

; ld hl, sfxBank_miz
; ld de,miz_buffer
; call mom_depack_rom

_StopFX::
    ld hl,#DATA_AREA
    ld b,#END_DATA_AREA-#DATA_AREA
    afxloop:
    ld (hl),#0
    inc hl
    djnz afxloop

    push ix
    ld ix,#0
    add ix,sp
    ld l,4(ix)
    ld h,5(ix)
    pop ix

    inc hl
    ld (afxBnkAdr),hl             ; reserve table address offsets

    xor a
    ld (afxNoisePeriod),a

    ld hl, #afxChData             ; mark all channels as empty
    ld de, #0x00ff
    ld b, #3

    afxInit0:
    ld (hl),d
    inc hl
    ld (hl),d
    inc hl
    ld (hl),e
    inc hl
    ld (hl),e
    inc hl
    ld (hl),d
    inc hl
    ld (hl),e
    inc hl
    ld (hl),d
    inc hl
    ld (hl),d
    inc hl
    ld (hl),d
    inc hl
    ld (hl),d
    inc hl
    ld (hl),d
    inc hl
    djnz afxInit0
    ret

; ------------------------------------------------- ------------- ;
; Playback of the current frame . ;
; With no parameters . ;
; ------------------------------------------------- ------------- ;

_UpdateFX::
    push ix

    ; ROUT
    ;out buffered sfx data
    xor a ; --- FIXES BITS 6 AND 7 OF MIXER ---
    ld hl,#afxAYREGS+afxMixer
    set 7,(hl)
    res 6,(hl)
    ld c,#0xA0
    ld hl,#afxAYREGS
    afxsfxloop:
    out (c),a
    inc c
    outi
    dec c
    inc a
    cp #13
    jr nz,afxsfxloop
    ;/out buffered sfx data



    ld ix, #afxChData
    ld b, #3
    afxFrameLoop:
    ld a, 1(ix) ; significant byte addresses effect
    or a ; if 0, the channel is not active
    jr z, afxFrameChSkip
    ld h, a
    ld l, 0(ix) ; low byte address effect

    ld a, (hl) ; read information bytes
    inc hl

    ld c, a
    ld 5(ix), a ; remember bits mixer
    and #15
    ld 4(ix), a ; remember volume

    bit 5 , c ; changing pitch period
    jr z, afxFrameNoTone

    ld a, (hl) ; remember period
    inc hl
    ld 6(ix), a
    ld a,(hl)
    inc hl
    ld 7(ix), a

    afxFrameNoTone:
    bit 6 , c ; period change noise
    jr z, afxFrameNoNoise
    ld a, (hl) ; period obtain
    cp #0x20 ; if it is more than 31 , the effect is over
    jr c, afxFrameNoise

    ld a,8(ix)
    and a
    jr z,afxa1
    ; looping effect
    ld l,9(ix) ; restart the effect from the beginning
    ld h,10(ix)

    ld 0(ix), l ; remember address
    ld 1(ix), h

    inc 2(ix) ; increment the playing time
    jr nz, afxFrameLoop
    inc 3(ix)
    jr afxFrameLoop

    afxa1: ; no loop
    xor a ; vanishes high byte address and the volume
    ld 1(ix), a
    ld 4(ix), a
    jr afxFrameChSkip

    afxFrameNoise:
    inc hl ; remember period noise
    ld (afxNoisePeriod), a

    afxFrameNoNoise:

    ld 0(ix), l ; remember address
    ld 1(ix), h

    inc 2(ix) ; increment the playing time
    jr nz, afxFrameChSkip
    inc 3(ix)

    afxFrameChSkip:
    ld de, #11 ; the next channel
    add ix, de
    djnz afxFrameLoop

    ; ld a, (afxAYREGS + AmplA)
    ; ld c, a
    ld a, (#afxChData+0 * 11 +4)
    ; cp c
    ; jr c, afxSkipCh0
    ld (#afxAYREGS + afxAmplA), a
    ld a, (#afxChData +0 * 11 + 6 )
    ld (#afxAYREGS + afxTonA +0), a
    ld a, (#afxChData +0 * 11 +7 )
    ld (#afxAYREGS + afxTonA +1), a

    ld a, (#afxAYREGS + afxMixer)
    and #0b11110110
    ld c, a
    ld a, (#afxChData +0 * 11 + 5 )
    rra
    rra
    rra
    rra
    and #0b00001001
    or c
    ld (#afxAYREGS + afxMixer), a

    afxSkipCh0:

    ; ld a, (afxAYREGS + AmplB)
    ; ld c, a
    ld a, (#afxChData +1 * 11 +4)
    ; cp c
    ; jr c, afxSkipCh1
    ld (#afxAYREGS + afxAmplB), a
    ld a, (#afxChData +1 * 11 + 6 )
    ld (#afxAYREGS + afxTonB +0), a
    ld a, (#afxChData +1 * 11 +7 )
    ld (#afxAYREGS + afxTonB +1), a

    ld a, (#afxAYREGS + afxMixer)
    and #0b11101101
    ld c, a
    ld a, (#afxChData +1 * 11 + 5 )
    rra
    rra
    rra
    and #0b00010010
    or c
    ld (#afxAYREGS + afxMixer), a

    afxSkipCh1:

    ; ld a, (afxAYREGS + AmplC)
    ; ld c, a
    ld a, (#afxChData +2 * 11 +4)
    ; cp c
    ; jr c, afxSkipCh2
    ld (#afxAYREGS + afxAmplC), a
    ld a, (#afxChData +2 * 11 + 6 )
    ld (#afxAYREGS + afxTonC +0), a
    ld a, (afxChData +2 * 11 +7 )
    ld (#afxAYREGS + afxTonC +1), a

    ld a, (#afxAYREGS + afxMixer)
    and #0b11011011
    ld c, a
    ld a, (#afxChData +2 * 11 + 5 )
    rra
    rra
    and #0b00100100
    or c
    ld (#afxAYREGS + afxMixer), a

    afxSkipCh2:

    ld ix, #afxChData
    ld a,5(ix) ; +0 * 11 +5
    and 16(ix) ; +1 * 11 +5
    and 27(ix) ; +2 * 11 +5
    rla
    jr c, afxNoNoise
    ld a, (afxNoisePeriod)
    ld (#afxAYREGS + afxNoise), a
    afxNoNoise:
    pop ix
    ret

; ------------------------------------------------- ------------- ;
; Running effect on the free channel. In the absence ;
; free channels selects the most long -sounding . ;
; Input : A = number of effect 0 .. 255 ;
; ------------------------------------------------- ------------- ;

_PlayFX::
    push ix

    ld ix,#0
    add ix,sp
    ld a,4(ix)

    push iy
    ex af,af'

    ld ix, #afxChData ; empty channel search
    ld de,#11
    ld b,#3
    afxb1:
    ;ld a,1(ix)
    or a
    jr z,afxfreechan
    add ix,de
    djnz afxb1
    ; no free channels

    ld iy, #afxChData ; search the channel that plays from more time
    ld ix, #afxChData ; in case of 3 looping channels use channel A
    ld de, #0 ; in de the longest time while searching
    ld bc,#11
    ld a, #3
    afxPlay0:
    inc 8(iy)
    dec 8(iy)
    jr nz, afxPlay1 ; skip channels with looping effects
    ld l, 2(iy) ; compare time channel with the highest
    ld h, 3(iy)
    sbc hl,de
    jr c, afxPlay1
    add hl,de ; remember the longest time
    ex de,hl
    push iy ; remember the address of the channel in ix
    pop ix
    afxPlay1:
    add iy,bc
    dec a
    jr nz,afxPlay0
    ; expect to address the effect
    afxfreechan:
    ld h, a
    ex af,af'
    ld l, a
    add hl, hl
    ld bc, (afxBnkAdr) ; address offset table effects
    add hl, bc
    ld c, (hl)
    inc hl
    ld b, (hl)
    add hl, bc ; effect address obtained in hl

    ld 0(ix), l ; record in the channel descriptor
    ld 1(ix), h
    ld 2(ix), #0 ; reset execution Time
    ld 3(ix), #0

    ld 8(ix), #0 ; reset looping flag

    cp #loopingsfx ; up to sfx $loopingsfx-1 will loop
    jr nc,afxc1

    ld 8(ix), #-1 ; set looping flag
    ld 9(ix), l ; record in the channel descriptor for later use
    ld 10(ix), h

    afxc1:
    pop iy
    pop ix
    ret
